CPU |
QCA9531+QCA9886 |
|
RF |
11n 2*2+11ac 2*2 MU-MIMO |
|
Flash |
16M |
|
SDRAM |
DDR2 128M |
|
Antenna |
3dBi Internal antenna x 4 |
|
Interface |
1 WAN ,1 LAN (PoE in) |
|
Button |
Reset |
|
System |
OPEN-WRT |
|
Work Mode |
Router,AP,Wireless Station |
|
WAN Type |
Dynamic IP /Static IP/PPPoE ,PPTP/L2TP/BigPond |
|
Port Forwarding |
Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port |
|
Standard |
802.11ac Wave 2,11ac,a/b/g/n ,IEEE 802.3AF |
|
Frequency Range |
2.4~2.4835Ghz 5.18~5.825Ghz |
|
Signal Rate |
1200Mbps (2.4GHz 300Mbps + 5.8GHz 867Mbps) |
|
Transmit Power |
Web Configurable 2.4Ghz-27dBm Max., 5.8Ghz-25dBm Max. |
|
Encryption |
64/128/152-bit WEP/WPA/WPA2 ,WPA-PSK ,WPA2-PSK |
|
Power Supply |
IEEE 802.3AF 48V |
|
Storage Temperature |
-45˚C～75˚C |
|
Dimension |
200*200*30mm |
|
Operate Temperature |
-25˚C～60˚C |
|
Operating Humidity |
95% ( Non-condensing) |
Description
OMY-K2 is Wave 2 Ceiling Access Point, Dual band 2.4Ghz + 5.8Ghz , wireless speed up to 1200Mbps with 100Mbps WAN / LAN port, 2.4Ghz Transmit power 500mW, 5.8Ghz Transmit power 300mW, this solution is an ideal wifi expand device for industrial use, such as supper market, Hall, Car and bus station...Features
- 802.11AC WAVE 2, 11AC,A/B/G/N Standards
- Wireless speed up to 1200Mbps
- Qualcomm chipset QCA9531+QCA9886
- Dual band 2.4Ghz & 5.8Ghz
- Web Configurable Transmit Power up to 500mW
- Support Open-WRT
- Power supply 802.3AF PoE
